Cartridge 7.62 x 51 mm for use in any NATO Standard 7.62 mm Caliber weapons, new or old, in single short or burst in diverse field conditions.
TECHNICAL DATA
Caliber
Length
Weight
Propellant
Material
7.62 mm Ball
70.36 ~ 71.12 mm
23.976 gm Approx
Single Base propellant NC-1055 (PCB)
Bullet J:G.M.
Case: Brass
7.62 Tracer
70.36 ~ 71.12 mm
23.392 gm Approx
Single Base propellant NC-1055 (PCB)
Bullet J:GMCS
Case: Brass
Performance
Caliber
Muzzle velocity
Accuracy
7.62 mm Ball
811 m/sec. at 27.43 meters
Mean Radii 203 mm at 457 meters
7.62 mm Penetrator
794 m/sec. at 27.43 meters
Mean Radii 305 mm at 457 meters
Packing
7.62 mm Ball
20 round packing in a carton
for rifle G-3
50 carton (1000 rds) packed in a Polythene bag.
Outer Packing steel box.
Net weight 24 kg. Gross weight 32 kg
Size of box 42.5 x 16.5 x 29.5 cm
7.62 mm Belted for MG-3
250 rds. linked in one belt DM-1, DM-6 or M-13
one belt packed in Plastic/Steel box.
04 boxes (1000 rds) packed in a wooden/steel crate.
Net weight 24 kg. Gross weight 36 ~ 41 kg.
Size of bex 41.38 x 33.6 x 28.3 cm
The packages are supplied with the standard marking.
